| Volts | 12v |
|---|---|
| BCI Group Number | DIN |
| Height with Terminal in. (mm) | 11.30" (287mm) |
| Width in. (mm) | 6.81" (173mm) |
| Length in. (mm) | 13.43" (341mm) |
| Weight lbs (kg) | 93.70 lbs (42.5 kg) |
| Terminal Configuration | M8 |
| CRANKING AMPS | |
| CA/MCA at 32°F | 950 Amps |
| CCA at 0°F | 795 Amps |
| NOMINAL CAPACITY | |
| Reserve Time @ 25 Amps | 260 min |
| Capacity @ 100 Hr Rate | 154 Ah |
| Capacity @ 20 Hr Rate | 140 Ah |
| Capacity @ 5 Hr Rate | 115Ah |
